4-13
INSTRUMENT CLUSTER
69TB-01E
Energy flow (if equipped)
The state of SHVS operation can be checked on the information display. For details, refer
to “SHVS (Smart Hybrid Vehicle by Suzuki)” (P.5-18).
Information display Description
69T040460
When the vehicle is running, ISG (Integrated Starter Generator)
assists engine power as an electric motor.
69T040470
When the vehicle is powered by the engine.
69T040490
When decelerating your vehicle, the ISG generates electricity
without engine power.
69T040480
When the engine automatically stops by the ENG A-STOP sys-
tem.
Vehicle speed
Vehicle speed is shown.
You can change the unit of velocity that
vehicle speed is displayed in. Refer to
“Setting mode of information display”
(P.12-8).
NOTE:
Displayed vehicle speed may differ a little
from the speed meter indication.
