4-43
INSTRUMENT CLUSTER
69TB-01E
Low fuel warning light
54G343
If this light comes on, refuel the fuel tank
as soon as possible.
When this light comes on, a ding sounds
once to remind you to refuel.
If you do not refuel, a ding sounds every
time when the engine switch is pressed to
change the ignition mode to ON.
NOTE:
• The activation point of this light varies
depending on road conditions (for exam-
ple, slope or curve) and driving condi-
tions because of fuel movement in the
tank.
Anti-lock Brake System (ABS)
warning light
80J127
When the engine switch is pressed to
change the ignition mode to ON, this light
comes on briefly so you can check that the
light is working.
If the light stays on or comes on when driv-
ing, there may be something wrong with
the ABS.
If this happens:
1) Pull off the road and stop carefully.
2) Change the ignition mode to LOCK
(OFF) by pressing the engine switch
and then start the engine again.
If the warning light comes on briefly and
then turns off, the system is normal. If the
warning light still stays on, something is
wrong with the system.
If the light and the brake system warning
light stay on or come on simultaneously
when driving, your ABS system is
equipped with the rear brake force control
function (proportioning valve function) and
there may be something wrong with both
the rear brake force control function and
the anti-lock function of the ABS system.
If one of the above occurs, have the sys-
tem inspected by an authorized SUZUKI
dealer or a qualified workshop.
If the ABS becomes inoperative, the brake
system will function as an ordinary brake
system that does not have this ABS sys-
tem.
For details of ABS system, refer to “Anti-
lock Brake System (ABS)” (P.5-153).
