9-49
INSPECTION AND MAINTENANCE
69TB-01E
License plate light
Since special procedures are required, it is
recommended that you take your vehicle
to an authorized SUZUKI dealer or a quali-
fied workshop for light replacement.
Rear fog light
69T090290
1) Remove the nuts (1) and then push the
rear fog light housing rearward.
69T090300
2) Turn the bulb holder counterclockwise
and pull it out.
69T090310
(3) Removal
(4) Installation
3) To remove the bulb of the rear fog light
(2) from bulb holder, push in the bulb
and turn it counterclockwise. To install a
new bulb, push it in and turn it clock-
wise.
(1)
To Next Page
