9-50
INSPECTION AND MAINTENANCE
69TB-01E
Interior light
If you need to replace the following bulbs
indicated in the above table, consult an
authorized SUZUKI dealer or a qualified
workshop.
Front
59RN09200
1) To prevent scratches, insert a commer-
cially available flat-blade screwdriver
covered with a soft cloth into the notch
(1), and then remove the lens (2).
69T090320
(3) Removal
(4) Installation
2) Pull the bulb (5) out and then insert a
new one.
3) After replacing the bulb, install the front
interior light lens in the reverse order of
removal.
Luggage compartment
69T090330
1) To prevent scratches, insert a commer-
cially available flat-blade screwdriver
covered with a soft cloth into the notch
(1), and then remove the lens (2).
ITEM:
Lights
WATTAGE BULB No.
Front 12V 10W –
Luggage
compart-
ment
12V 5W –
(3)
(4)
(5)
