10-23
EMERGENCY SERVICE
69TB-01E
59RN10120
59R80200
6) Position the jack (if equipped) at an
angle as shown in the illustration and
raise the jack by turning the jack handle
(if equipped) clockwise until the jack-
head groove fits around the jacking bar
beneath the vehicle body
81PN117
7) Continue to raise the jack (if equipped)
slowly and smoothly until the tyre clears
the ground. Do not raise the vehicle
more than necessary.
(1)
(1)
WARNING
Use the jack only to change wheels
on level, hard ground.
Never jack up the vehicle on an
inclined surface.
Never raise the vehicle with the
jack in a location other than the
specified jacking point (shown in
the illustration) near the wheel to
be changed.
Check that the jack is raised at
least 25 mm (1 inch) before it con-
tacts the flange. Use of the jack
when it is within 25 mm (1 inch) of
being fully collapsed may result in
failure of the jack.
Never get under the vehicle when it
is supported by the jack.
Never run the engine when the
vehicle is supported by the jack.
If there are passengers or heavy
luggage, get them out of the vehi-
cle.
