2-39
FOR SAFE DRIVING
69TB-01E
Child restraint systems installation
suitability for each seat position
(for the vehicle without airbag deac-
tivation switch)
83RS034
NOTE:
The above illustration shows Left hand
drive vehicle.
Seat position number of , , and
is same as Left handle drive vehicle
for Right handle drive vehicle.
Front passenger’s seat
Rear seat right side
Rear seat center
Rear seat left side
#1: Move the front seat fully rearward.
#2: When you install a forward-facing child
restraint, if there is a gap or space
between the child restraint and the
seatback, adjust the seatback angle in
order to install the child restraint sys-
tem properly.
#3: If the head restraint interferes with the
child restratint system, adjust the
height of the head restraint or remove
it, as necessary.
#4: If there is a gap or space between the
child restraint system and the seat-
back, put cushions, etc. into it in order
to install properly.
(#1, #2, #3)
(#3, #4)
(#3, #4)
(#3, #4)
It is suitable for universal
category of child restraint
system fixed with the
vehicle seat belt.
It is suitable for i-Size
and ISOFIX child
restraint system.
This seat is equipped
with Top tether anchor-
age point.
Never use a rear-facing
child restraint system on
the passenger seat.
It is not suitable for child
restraint system.
To Next Page
