2-46
FOR SAFE DRIVING
69TB-01E
Here is a general instruction:
NOTE:
Stow the removed head restraint in the lug-
gage compartment so it will not cause
inconvenience to the occupants.
69T020090
1) When the child restraint system con-
tacts the head restraint, adjust the
height of the head restraint or remove it
for fitting the child restraint system.
2) Check that the rear seat is securely
fixed.
69T020180
3) Place the child restraint in the rear seat,
inserting the connecting bars (3) to the
lower anchorages (4) between the seat
cushion and the seatback.
CAUTION
If your vehicle is equipped with the
head restraint, adjust the height of
the rear head restraint or remove it
for fitting the child restraint, as nec-
essary. However, if a booster cushion
not equipped with the head restraint
is fitted, the head restraint should not
be removed. If the head restraint is
removed for fitting the child restraint,
you need to install it again after
removing the child restraint.
If the child restraint is fitted improp-
erly, a child sitting in it could be
injured in a collision.
WARNING
• If the child restraint system con-
tacts the head restraint, the child
restraint system cannot be secured
firmly. This may cause severe
injury to a child in a collision.
When installing the child restraint
system, adjust the head restraint
height to the highest position as
much as possible or remove the
head restraint so that the child
restraint system would not contact
the head restraint.
(Continued)
(Continued)
• If you install a junior seat without a
seatback to a seat without a head-
rest, a child may be severely
injured in a collision.
When installing a junior seat with-
out a seatback, install a head
restraint.
WARNING
(3)
(3)(3)
(4)
To Next Page
