HOW TO USE THIS MANUAL
TO LOCATE WHAT YOU ARE LOOKING
FOR:
1. The text of this manual is divided into sections.
2. The section titles are listed in the GROUP INDEX.
3. Holding the manual as shown at the right will allow
you to find the first page of the section easily.
4. The contents are listed on the first page of each sec-
tion to help you find the item and page you need.
COMPONENT PARTS AND WORK TO BE DONE
Under the name of each system or unit, is its exploded view. Work instructions and other service information
such as the tightening torque, lubricating points and locking agent points, are provided.
Example: Front wheel
1 Front axle
2 Spacer
3 Brake disc
4 Bearing
5 Front wheel
6 Spacer
7 Speedometer gearbox
A Front axle nut
B Brake disc bolt
ITEM N·m kgf-m
A 42 4.2
B 23 2.3
