Suzuki VLR1800 Service Manual

General Information: 0A-8
42
29
33
40
24
25
28
30
32
27
26
41
43
31
34
38
37
36
35
39
I822H1010008-05
24. Fuel level gauge 34. Regulator/Rectifier
25. Fuel pump 35. Oil pressure switch
26. Battery 36. Generator
27. ECM (Engine Control Module) 37. CKP sensor
28. Fuse box 38. Speedometer sensor
29. Ignition coil (#2) 39. Side-stand switch
30. Mode selection switch coupler 40. Ignition coil/Plug cap (#2)
31. Ignition switch 41. EVAP system purge control solenoid valve (For E-33)
32. Starter relay/Main fuse 42. PAIR control solenoid valve
33. PAIR control solenoid valve (For E-02, 19, 24, 33) 43. TO sensor

Suzuki VLR1800 Specifications

General

Manufacturer	Suzuki
Model	VLR1800
Compression Ratio	10.5:1
Fuel System	Fuel injection
Starter	Electric
Transmission	5-speed
Category	Cruiser
Displacement	1783 cc
Ignition	Electronic ignition (Transistorized)
Final Drive	Shaft
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Rear Brakes	Single disc
Ground Clearance	140 mm
Seat Height	705 mm
