DESCRIPTION
ACCESSORIES
PARTS
PARTS NAME
QUANTITY
Hose inlet
Exhaust hose
Hose outlet
1 set
Window slider kit
1 set
Remote control
Battery
1 set
Drainage hose
1 set
Note: All the illustrations in this manual are for explanatory purposes only. Your appliance
1.Control panel
2.Handle
（
both side)
3.Castors
4.Deflector
5.Intake grille
6.Air outlet grille
7.Intake grille 8.Power cable
9.Plug fixer
10.Middle condenser drain
11.Condenser drain
