may be slightly different.
Be sure all accessories are removed from the packing before use.
Installation Instructions
EXHAUSTING HOT AIR
In the Cool Mode the appliance must be placed close
to a window or opening so that the warm exhaust
air can be ducked outside.
First position unit on a flat floor and make sure there's
a minimum of 17.7" (45cm) clearance around the unit,
and is within the vicinity of a single circuit outlet
power source.
1. Extend either side of the hose (Fig.1)
2. Screw the hose inlet (Fig.2).
3. Screw it to the hose inlet (Fig.3).
4. Install the hose inlet into the unit (Fig.4).
5. Affix the hose outlet into the window slider kit and seal. (Fig.5 &6).
