AUDIO INPUT
CD
DVD
Power cord
Active speaker Passive speaker
2RCA to mini-jack
signal cable
2RCA to 2RCA
signal cable
Fig. 2. Connection diagram
PC
• Adjust the volume level by turning the VOLUME control knob b. By turning the knob clockwise,
you increase the volume level, and by turning the knob counterclockwise, you reduce it.
• Adjust the bass and treble levels by turning the TREBLE control knob d and the BASS control
knob c respectively. By turning the knobs clockwise, you increase the treble/bass level, by turning
the knobs counterclockwise, you reduce it.
Notes:
• After using the MSS, mind to switch it off using the POWER i switch and unplug the
power cord from the mains socket.
• To improve the sound quality, use the Line-Out port of your sound card.
Player
SUBWOOFER
Built-in
audio cable
ENG
4
2.0 Multimedia Speaker System
