Sven MS-1090 - Installation and Operation; Player Mode

USB/SD card
connection
• To connect the MSS to a DVD player or TV, use a 2RCA to 2RCA stereo signal cable (not included).
Insert the RCA jacks of the cable into the AUDIO INPUT jack k, and connect the other RCA jacks to
the audio output jack of your DVD/CD player.
Note. The sound is directly dependent on accuracy and reliability of the cable connections.
It’s recommended that you use the cables supplied with the speakers.
• Insert the power cord plug n (see Fig. 2) on the subwoofer rear panel into the mains outlet .
• Set the subwoofer volume to the minimum by turning the BASS +/- knob j on the subwoofer rear
panel counterclockwise until it stops.
• Switch on the device using the POWER switch (m, ON position) on the subwoofer rear panel.
• Select an audio source (AUDIO INPUT or USB/SD) with the MODE button d on the subwoofer front
panel or the MODE button j on the remote control.
• Adjust the volume level by turning the BASS +/- knob j on the subwoofer rear panel, and then –
using buttons VOL+ b or VOL- c on the subwoofer front panel or buttons -/+ e on the remote
control (Fig. 4).
• The MUTE function is designed for switching on/off the sound of the MSS. To switch the sound
on, press the MUTE button g (Fig. 4) on the remote control again.
Player mode
• To switch to the Player mode, insert a USB or SD storage device into the corresponding port
(USB p or SD CARD o) (Fig. 3) when the MSS is on. Then press the MODE button d on the front
panel or the MODE button j on the remote control. The playback will start automatically. The LED
g on the front panel will blink green.
• To select the AUDIO INPUT, press the MODE button j on the remote control or the MODE button
d on the front panel. The LED g will light up red.
Fig. 5. Connection diagram
2RCA to mini-jack
signal cable
PC
Player
or
2RCA to 2RCA
signal cable
SD
CD
DVD
ENG
5
Operation Manual
MS-1090
