ƴctive speaker
Passive speaker
i
j
k
Speaker panels
a Tweeter
b Woofer
c Headphone jack
d Power LED
e POWER: power switch
f BASS: bass control knob
g VOLUME: volume control knob
5. PREPARATION AND OPERATION
Speaker placement
• Place the speakers symmetrically to the listener at least one meter away.
• Place MSS far away from TV sets, as insigniԛcant image distortion in these supersensitive
devices is possible.
L R SUB OUT
~220V/50Hz
Fig. 2. Rear panels
BASS
VOLUME
TREBLE POWER
Fig. 1. Front panel
b
c
a
d
e
h
fg
l
h TREBLE: treble control knob
i Terminals for connecting speakers
to each other
j SUB OUT: subwoofer output
k L/R: stereo input for various audio devices
l Power cord
ENG
3
Operation Manual
MS-230
