TASK
:
Finish Setting Up your AVR or Pre/Pro
If your AVR or Pre/Pro IS equipped with Audyssey MultEQ:
Remove the SAT Output connection from your AVR or Pre/Pro, and ensure your AVR or Pre/Pro’s
Subwoofer Pre-Out is attached to the appropriate Input of the AS-EQ1. Following the instructions
provided with your AVR or Pre/Pro, and with your AVR or Pre/Pro’s Mic attached to the AVR or Pre/Pro
(
NOT the AS-EQ1) perform the MultEQ setup and calibration. The AS-EQ1 should be powered on, enabled
and in the signal path, and your Subwoofer(s) on and set from the AS-EQ1 calibration.
After finishing your MultEQ setup and calibration on your AVR or Pre/Pro, check the subwoofer trim
level in your AVR or Pre/Pro set-up menu. If your Sub trim is between -3.5 dB and +3.5 dB your AS-EQ1 is
now successfully integrated into your audio system. If the subwoofer trim level falls outside the range of
+/- 3.5 dB, please contact SVS (techsupport@svsound.com) to determine if additional action is necessary.
Remove the SAT Output connection from your AVR or Pre/Pro, and ensure your AVR or Pre/Pro’s Subwoofer
Pre-Out is attached to the appropriate Input of the AS-EQ1. Using your AVR or Pre/Pro’s Setup menu, enter
the Distance and Trim level for your subwoofer(s) given in the Detection Results screen. If your Sub trim
is between -3.5 dB and +3.5 dB your AS-EQ1 is now successfully integrated into your audio system. If
the subwoofer trim level falls outside the range of +/- 3.5 dB, please contact SVS (techsupport@svsound.com) to
determine if additional action is necessary.
If your AVR or Pre/Pro is NOT equipped with Audyssey MultEQ:
Calibrating the AS-EQ1 in Your Listening Environment
32
