AMPLIFIER
FEATURES
&
CONTROLS
ti!\
Line
Level
Inputs
\::-1
These
inputs
are
used
for
line
level
connections
to
the
subwoofer.
For
a
single
mono
connection
to
an
AN
receiver,
use
the
R/LFE
input.
For
2-channel
applications,
use
both
the
Land
R
inputs.
r-i\
Line
Level
Outputs
\:J
These
outputs
are
used
in
2-channel
applications
to
high
pass
the
signal
being
sent
to
the
loudspeaker
amplifier.
The
line
level
outputs
feature
a
fixed
80
Hz
12
dB/octave
high
pass
filter.
10\
High
Level
(Speaker
Level)
Inputs
\!-/
This
connection
method
is
for
2-channel
stereo
applications
where
the
integrated
pre/pro/amplifier
only
has
high
level
(i.e.,
speaker
level)
outputs.
10\
Main
Power
Switch
\:!1
This
switch
turns
the
amplifier
on
and
off.
During
normal
operation,
the
main
power
switch
can
be
left
on.
It
should
be
turned
off
during
extended
periods
of
non-use,
or
when
making
signal
connections
to
the
subwoofer.
tin\
Power
Cord
Receptacle
~
The
receptacle
accepts
the
AC
power
cord.
ti1\
Power
Status
Light
(front
panel)
\:.!1
The
power
status
light
is
located
on
the
front
panel
of
the
subwoofer
in
the
upper
left
corner.
The
light
will
illuminate
blue
when
the
amplifier
is
on.
The
light
will
illuminate
red
when
the
amplifier
is
in
standby
mode.
