PC-2000 Pro
SUBWOOFER
CONNECTING & CONTROLLING YOUR SUBWOOFER
Enable and adjust the on-board low pass filter of the PC-2000 Pro for a smooth blend with the
main speakers.
NOTE: For additional guidance on speaker/subwoofer crossover settings, please consult our SVS Sound
Experts or our Merlin subwoofer matching tool at www.svsound.com/merlin.
www.svsound.com • custservice@svsound.com • (877) 626-5623
Line Level Connection – Stereo Receiver or Preamplifier Left/Right Channels (cont’d)
RL
+
VOL
LOW
PASS
LOW PASS
PHASE
PHASE
0°
90° 180°
30Hz 40Hz 60Hz 90Hz 140Hz LFE
_
LINE LEVEL
INPUT OUTPUT
LFE
LINE LEVEL OUTPUTS
REAR FRONT
R
L
RECEIVER/PREAMP
To Next Page
