Swegon CASA Smart - Control Curves; Basic Ventilation; Boosted Ventilation

EN
47
Swegon reserves the right to alter specications.
2020-12-22
Blues | Salsa | Samba | Tango | Jazz
8.4 Control curves
8.4.1 Basic ventilation
8.4.2 Boosted ventilation
0
20
40
60
80
10
0
12
0
14
0
16
0
18
0
200
15 20 25 30 35 40 45 50 55 60 65 70 75 80
Air flow rate (l/s)
Pressure differential (Pa)
Air flow rate (l/s)
Pressure differential (Pa)
Open holes in the damper
1 2 3 4 5 6 7 8
0
25
50
75
10
0
12
5
15
0
17
5
20
0
22
5
250
3456789101112131415161718192021
Open
hole
K
value:
1 0.31
2 0.44
3 0.53
4 0.65
5 0.80
6 0.98
7 1.17
8 1.31
