Blues | Salsa | Samba | Tango | Jazz
Setting the power roof ventilator speed:
set three speeds for the power roof ventilator,
so that the required air volumes are reached.
The factory settings for the control voltages
are Away = 2 V, Home = 5 V, Boost = 8 V.
• Press and hold the speed selector and
lighting (
+ ) simultaneously for about
five seconds.
• The mode to be set is selected with the
fan speed selector button . The fan speed
indication shows which mode is being set.
NOTE! The fan speeds for the operating
modes can only be set in the order low to
high, for example, the Away mode speed
cannot be higher than the Home mode
speed.
• Increase the control voltage with the
lighting button and reduce it with the
damper control button . The selected
control voltage is indicated according to
the following:
• Acknowledge the implemented settings by
pressing the lighting button
for about
five seconds. If you do not acknowledge
and do not touch any of the hood’s but-
tons for ten minutes, the cooker returns
to normal mode, and the settings are not
saved.
Not lit
Short flash
Long flash
Lit
1 V
2 V
3 V
4 V
5 V
6 V
7 V
8 V
9 V
10 V
