14
Operation and maintenance instructions
EXCHANGER SIZE AIR VOLUME A [mm] B [mm] C [mm] Weight [kg]
GLOBAL LP
Counterow
02 580 m³/h 160 l/s 1300 890 350 105
04 650 m³/h 180 l/s 1300 1100 350 125
06 1000 m³/h 280 l/s 2100 1050 435 195
08 1420 m³/h 395 l/s 2100 1300 435 230
10 1800 m³/h 500 l/s 2180 1600 435 285
12 2200 m³/h 610 l/s 2350 1700 510 335
13 2550 m³/h 705 l/s 2350 1700 510 335
14 2870 m³/h 795 l/s 2350 1940 510 370
16 3300 m³/h 915 l/s 2900 1935 660 610
18 3720 m³/h 1030 l/s 2900 1935 660 610
AIR VOLUMES AND DIMENSIONS GLOBAL LP
GLOBAL LP
GLOBAL LP
