swepac F 50 - Technical Data; Function

6
F 50
F50 / F75
Doc: 101425E-GB 1406
F 50
Net weight .................................52 kg
Base plate, w x l .......................300 x 500 mm
Speed .........................................appr 25 m/min
Centrifugal force .......................9 kN
Vibration frequency ..................115 Hz
Drive engine ...............................Honda GX100
Engine power ............................1,7 kW
Engine RPM ..............................3600 RPM
Fuel tank volume .......................1,6 liter
Fuel type ....................................Unleaded petrol or alkylatet
Oil quantity, crankcase ..............0,4 liter
TECHNICAL DATA FUNCTION
The machine consists of a base plate with a vibration
element and an upper part cushioned from the base plate.
The power is transmitted from the petrol engine to the
vibration element via a V-belt.
The engine is tted with an integrated centrifugal clutch.
On account of the direction of rotation and the position of
the vibration element at the front end of the base plate, the
vibrator moves forward under its own power. The moving
parts are well protected by a cover made of impact resistant
ABS.
FUEL AND OIL RECOMMENDATIONS
Fuel ..............................Unleaded petrol or alkylate
Engine oil .....................SAE10W-30
Engine oil change: rst oil change after 20 hours then every
100 hours of operation
F 75
Net weight .................................75 kg
Base plate, w x l .......................380 x 530 mm
Speed .........................................appr 25 m/min
Centrifugal force .......................11 kN
Vibration frequency ..................94 Hz
Drive engine ..............................Honda
Engine power ............................2,9 kW
Engine RPM ..............................3600 RPM
Fuel tank volume .......................2,5 liter
Fuel type ....................................Unleaded petrol or alkylatet
Oil quantity, crankcase ..............0,6 liter
