9
F 50
F50 / F75
Doc: 101425E-GB 1406
Choke
Throttle lever
Starting handle
Engine switch
AFTER STARTING
Open the choke gradually.
Run the engine warm for around 5 minutes.
STOPPING
Switch the engine to idle and let it run for a few minutes.
Shut off the engine, by setting the red engine switch to
position O.
OPERATING INSTRUCTIONS
The machine’s vibration elements start when the throttle is
increased. The best packing is achieved at full engine RPM.
Avoid running the engine at other RPM as there is a risk of
the clutch slipping, with abnormal wear as a result.
Thanks to its compact design and low weight, the
machine’sis very easy to manoeuvre. The design of the base
plate allows the machine to be pulled backwards without
disturbing the packed surface. The machine’s vibration
element stops when the throttle is switched to idle.
The machine is only designed to be used outdoors. Work
with the machine in daylight or other adequate lighting.
Ballast must be wetted or naturally damp. All other use is
discouraged.
Fuel shut-off valve
BEFORE STARTING GX 100 ENGINE
Also see Daily Checks on page 8.
STARTING
Set the choke to CHOKE-position.
Set the throttle lever to FAST-position.
Open the fuel shut-off valve.
Move the engine switch to position I.
Start by pulling the starting handle.
Off
On
