Swiss Timing StartTime V - @-GUN Device Controls and Indicators; @-GUN LED and Key Functions

ELECTRONIC START SYSTEM / E-GUN & StartTime V
Version 1.2 3481.560.02 Page 5
1.9
LED / Key
Description
TALK
Indication of the selected audio channel
Mode SPEAK selected
READY 1
Indication that the main timing device is ready (MAIN / PRIMARY)
READY 2
Indication that the additional timing device is ready (BACKUP / SECONDARY)
FLASH CHARGE
Indication that the flash system is recharging
(( )) Mode TEST selected (without gun shot sound)
KEYPADS
Allow starter to select the audio channel
1x Mode SPEAK
+ 1x Mode TEST
TRIGGER
Allows starter to start the TIMER
