GRAN MILANO
SILVER VASE / GRAN TURISMO
SILVER VASE
GRAN TURISMO
GRAN MILANO
SILVER VASE / GRAN TURISMO
EN
EN - 19
THROTTLE CONTROL
The throttle twistgrip (1) is located on the right-
hand side of the handlebar.
FRONT BRAKE CONTROL
The brake control lever (2) is located on the right-
hand side of the handlebar. A stop switch, during
the braking action, causes the stop light on the tail
light to come on. The position of the throttle con-
trol can be adjusted by loosening the two retaining
screws (B).
CAUTION*: Do not forget to tighten the screws
(B) after the adjustment.
CLUTCH CONTROL
The clutch control lever (1) is located on the left-
hand side of the handlebar and is equipped with a
protection.
The clutch control position on the handlebar can be
adjusted by loosening the retaining screws (A).
CAUTION*: Do not forget to tighten the screws
after adjustment.
