SILVER VASE
GRAN TURISMO
GRAN MILANO
GRAN MILANO
SILVER VASE
GRAN TURISMO
EN - 20
REAR BRAKE CONTROL
The rear brake control (1) is placed on the right-
hand side of the motorcycle. A stop switch, during
the braking action, causes the stop light on the tail
light to come on.
GEAR SHIFT CONTROL
The lever (1) is placed on the left-hand side of the
engine. The operator must release the lever after
each gear change to allow it to return to its central
position. Neutral position (N) is between the first
and second gears.
First gear is engaged by pushing the lever down-
wards; the other gears are engaged in a sequence
by pushing the lever upwards.
The position of the gear shift lever on the shaft can
be varied as follows: loosen the screw, pull the
lever out, and place the lever in a new position on
the shaft.
Tighten the screw once operation is completed.
CAUTION*: Do not shift gears without disen-
gaging the clutch and closing the throttle. The
engine could be damaged by overspeed.
WARNING*: Do not downshift when travelling
at a speed that would force the engine to over-
rev in the next lower gear, or cause the rear
wheel to lose grip.
