SWM VAREZ 125 - Page 98

EN - 46
Cable Colour Key
ACRONYM COLOUR
B Blue
B/Bk Blue/Black
Bk Black
Br Brown
Br/Bk Brown/Black
Br/R Brown/Red
Br/W Brown/White
Bk/W Black/White
G Green
G/Bk Green/Black
G/Br Green/Brown
G/Gr Green/Grey
G/R Green/Red
Gr Grey
Gr/B Grey/Blue
Gr/Bk Grey/Black
O Orange
O/Bk Orange/Black
O/G Orange/Green
O/W Orange/White
O/Y Orange/Yellow
Pk Pink
R Red
R/G Red/Green
R/V Red/Violet
R/Bk Red/Black
Sb Soft blue
V Violet
V/G Violet/Green
W White
W/B White/Blue
W/Bk White/Black
W/G White/Green
W/O White/Orange
W/R White/Red
W/V White/Violet
W/Y White/Yellow
Y Yellow
Y/Bk Yellow/Black
Y/Br Yellow/Brown
Y/G Yellow/Green
Y/O Yellow/Orange
Y/Sb Yellow/Soft blue
Y/B Yellow/Blue
Y/R Yellow/Red
Wiring Diagram Key
1. Electronic control unit
2. Control unit interface
3. Power supply / Recharge
4. Coolant temperature sensor
5. H.V. coil
6. Fuel pump
7. Clutch switch
8. Relay for electric fan
9. Ignition switch
10. Lambda sensor
11. Cooling fan
12. Speed sensor
13. Direct current relay
14. LH Switch
15. Instrument
16. Battery
17. Electric starting contactor
18. Starter motor
19. Voltage regulator
20. Alternator
21. Gear sensor
22. Throttle position sensor
23. Pressure sensor
24. Power relay
25. Main fuse unit
26. Side stand sensor
27. RH Switch
28. Injector
29. By-pass Valve
30. Horn
31. Turning indicator intermittence
32. Front stop switch
33. Rear stop switch
34. Rear RH turning indicator
35. Tail light
36. Rear LH turning indicator
37. Front LH turning indicator
38. Headlight
39. Front RH turning indicator
40. Secondary fuse unit
41. Fuel level sensor
