36
Brompton Specific
1.1
2.2
Stick the sensor onto the down tube of the Brompton. Angle
the sensor so it’s sitting within 3mm of the magnetic disc, using
spacers if needed.
3mm gap
Angle the pedal sensor by loosening
the bolt and pointing the sensor
target towards the magnetic disc.
2 x spacers
Tighten the sensor screw to lock
it in position and add cable ties to
secure it to the frame.
3.
Pedal Sensor
