Sycamore 3500L - Page 23

3500 Watt Generator
© 2006, Sycamore SCS, LLC.
22
Engine Parts Listing (cont’d)
Figure D (cont’d)
ITEM
NO.
DESCRIPTION PSYCG # QTY.
ITEM
NO.
DESCRIPTION PSYCG # QTY.
D01 BREATHER PIPE PSYCG3500LD01 1
D33 CYLINDER HEAD COVER GASKET PSYCG3500LD33 1
D02 CYLINDER HEAD BOLT M10x55 PSYCG3500LD02 4
D34 GOVERNOR SPRING PSYCG3500LD34 1
D03 CYLINDER HEAD COVER BOLT M6x4 PSYCG3500LD03 4
D35 BOLT M6x10 PSYCG3500LD35 1
D04 CYLINDER HEAD COVER PSYCG3500LD04 1
D36 HIGH TENSION LINE PSYCG3500LD36 1
D05 LOCK NUT PYSCG3500LD05 2
D37 IGNITION COIL PSYCG35000LD37 1
D06 ADJUSTING SCREW PYSCG3500LD06 2
D38 NUT (SPECIAL 14MM) PSYCG35000LD38 1
D07 ROCKER ARM PSYCG3500LD07 3
D39K
PULL START ASSEMBLY (D39-47,
95, 96)
PSYCG3500LD39K
1
D08 ROCKER ARM BOLT M8-M6x55 PYSCG3500LD08 2
D39 STARTER RATCHET SPRING PSYCG3500LD39 2
D09 VALVE PUSH ROD GUIDING BOARD PSYCG3500LD09 1
D40 START ROPE PSYCG3500LD40 1
D10 VALVE PUSH ROD PSYCG3500LD10 2
D41 START HANDLE PSYCG3500LD41 1
D11 CYLINDER HEAD PSYCG3500LD11 1
D42 STARTING CASE ASSEMBLY PSYCG3500LD42 1
D12 CARBURETOR SHIELD PSYCG3500LD12 1
D43 SPIRAL SPRING PSYCG3500LD43 1
D13 CARBURETOR GASKET PYSCG3500LD13 1
D44 STARTING WHEEL PSYCG3500LD44 1
D14 CARBURETOR PSYCG3500LD14 1
D45 CIRCULAR CLIP PSYCG3500LD45 1
D15 AIR CLEANER CASE PSYCG3500LD15 1
D46 STARTING RATCHET PSYCG3500LD46 2
D16 AIR CLEANER SEAL PSYCG3500LD16 1
D47 FRICTION PLATE SCREW PSYCG3500LD47 1
D17 AIR CLEANER SERARATOR PSYCG3500LD17 1
D48 FAN COVER PSYCG3500LD48 1
D18 AIR CLEANER COVER PSYCG3500LD18 1
D49 STARTER PULLEY PSYCG3500LD49 1
D19 AIR CLEANER ELEMENT PSYCG3500LD19 1
D50 COOLING FAN PSYCG3500LD50 1
D20 BOLT M5x14 PSYCG3500LD20 4
D51 FLYWHEEL MAGNET PSYCG3500LD51 1
D21 CHOKE LEVER PSYCG3500LD21 1
D52 CYLINDER BLOCK PSYCG3500LD52 1
D22 CARBURETOR PACKING PYSCG3500LD22 1
D53 SPEED CONTROL LEVER PSYCG3500LD53 1
D23 STUD BOLT M6x96 PSYCG3500LD23 2
D54 GOVERNOR ARM PSYCG3500LD54 1
D24 INTAKE VALVE PSYCG3500LD24 1
D55 GOVERNOR SPRING PSYCG3500LD55 1
D25 EXHAUST VALVE PSYCG3500LD25 1
D56 GOVERNOR SUPPORT PSYCG3500LD56 1
D26 CYLINDER HEAD GASKET PSYCG3500LD26 1
D57 BOLT M6x12 PSYCG3500LD57 2
D27 EXHAUST PIPE STUD PSYCG3500LD27 2
D58 OIL ALERT NUT M10 PSYCG3500LD58 1
D28 SPARK PLUG PSYCG7000EG08 1
D59 PLUG M10x15 PSYCG3500LD59 2
D29 VALVE GUIDE PSYCG3500LD29 2
D60 PLUG WASHER PSYCG3500LD60 2
D30 VALVE SPRING PSYCG3500LD30 2
D61 OIL SENSOR PSYCG7000EH17 1
D31 ROCKER SHAFT CIRCULAR CLIP PSYCG3500LD31 2
D62 BOLT M6x12 PSYCG7000EH18 2
D32 VAVLE STEM PROTECTOR PSYCG3500LD32 2
D63 CRANK SHAFT PSYCG3500LD63 1
