Sycamore 3500L - Page 24

Owner's Manual
© 2006, Sycamore SCS, LLC.
23
Engine Parts Listing (cont’d)
Figure D (cont’d)
ITEM
NO.
DESCRIPTION PSYCG # QTY.
ITEM
NO.
DESCRIPTION PSYCG # QTY.
D64 CRANK SHAFT GEAR PSYCG3500LD64 1
D83 GOVERNOR ARM NUT M6 PSYCG3500LD83 1
D65 OIL DIPSTICK PSYCG3500LD65 2
D84 GOVERNOR ARM PSYCG3500LD84 1
D66 OIL DIPSTICK SEAL RING PSYCG3500LD66 2
D85 GOVERNOR ARM BOLT M6x20 PSYCG3500LD85 1
D67 GEAR CASING PSYCG3500LD67 1
D86 SPRING PULL ROD PSYCG3500LD86 1
D68 BOLT M8x30 PSYCG3500LD68 6
D87 PULL ROD PSYCG3500LD87 1
D69 GEAR CASE PACKING PYSCG3500LD69 2
D88
CYLINDER COVER LOCATING
RING Ø10
PSYCG3500LD88 1
D70 CRANK SHAFT BEARING PSYCG3500LD70 2
D89 ROCKER SHAFT CIRCLIP PSYCG3500LD89 1
D71 CAMSHAFT ASSEMBLY PSYCG3500LD71 1
D90
CONTROL ASSEMBLY FLANGED
BOLT M6x12
PSYCG7000EH06 1
D72 LOCATLNG RING PSYCG7000EH20 4
D91 CONTROL ASSEMBLY PSYCG3500LD91 1
D73 OIL SEAL PYSCG3500LD73 2
D92 VALVE LIFTER PSYCG3500LD92 1
D74 CONNECTING ROD BOLT PYSCG3500LD74 2
D93 CYLINDER GASKET PSYCG3500LD93 1
D75 CONNECTING ROD CAP PYSCG3500LD75 1
D94 AIR CLEANER ELEMENT B PYSCG3500LD94 1
D76 CONNECTING ROD PYSCG3500LD76 1
D95
STARTING CASE WASHER
Ø6xØ10
PSYCG7000EH47 1
D77 PISTON PSYCG3500LD77 1
D96
STARTING CASE FLANGED BOLT
M6x8
PSYCG7000EH01 1
D78
COMPRESSION PING Ⅰ
PYSCG3500LD78 1
D97
FLYWHEEL COVER FLANGED
BOLT M6x20
PSYCG3500LD97 1
D79
COMPRESSION PING Ⅱ
PYSCG3500LD79 1
D98 FLYWHEEL COVER PSYCG3500LD98 1
D80 OIL SCRAPER RING PSYCG3500LD80 1
D99 OIL COVER PYSCG3500LD99 1
D81 PISTON PIN PSYCG3500LD81 1
D100 IGNITION COIL BOLT M6x25 PYSCG3500LD100 2
D82 PISTON PIN CIRCLIP PSYCG3500LD82 2
