20020206 3-3-11 T5307EL
SENSOR CBA
C507 ELECTROLYTIC CAP. 47µF/25V M or CE1EMASDL470
ELECTROLYTIC CAP. 47µF/25V M CE1EMASTL470
C510 CERAMIC CAP. B K 1000pF/2KV or CCD3DKP0B102
CERAMIC CAP. B K 1000pF/2KV or CA3D102MR030
CERAMIC CAP. B K 1000pF/2KV CCD3DKD0B102
CONNECTORS
CN501 PIN CONNECTOR 005P-5100 or JTEA001TG001
CONNECTOR PIN, 1P LV or 1700576
CONNECTOR PIN, 1P RT-01N-2.3A 1730688
COIL
L501 PCB JUMPER D0.6-P5.0 JW5.0T
TRANSISTORS
Q501 TRANSISTOR 2SC2482 TPE6 or QQSZ02SC2482
TRANSISTOR 2SC3468(E)-AE or QQSE02SC3468
TRANSISTOR 2SC3468(D)-AE or QQSD02SC3468
TRANSISTOR KTC3207 NQSZ0KTC3207
Q502 TRANSISTOR 2SC2482 TPE6 or QQSZ02SC2482
TRANSISTOR 2SC3468(E)-AE or QQSE02SC3468
TRANSISTOR 2SC3468(D)-AE or QQSD02SC3468
TRANSISTOR KTC3207 NQSZ0KTC3207
Q503 TRANSISTOR 2SC2482 TPE6 or QQSZ02SC2482
TRANSISTOR 2SC3468(E)-AE or QQSE02SC3468
TRANSISTOR 2SC3468(D)-AE or QQSD02SC3468
TRANSISTOR KTC3207 NQSZ0KTC3207
RESISTORS
R501# METAL OXIDE FILM RES. 1W J 15k Ω or RN01153ZU001
# METAL OXIDE FILM RES. 1W J 15k Ω RN01153DP003
R502# METAL OXIDE FILM RES. 1W J 15k Ω or RN01153ZU001
# METAL OXIDE FILM RES. 1W J 15k Ω RN01153DP003
R503# METAL OXIDE FILM RES. 1W J 15k Ω or RN01153ZU001
# METAL OXIDE FILM RES. 1W J 15k Ω RN01153DP003
R504 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R505 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R506 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R507 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R508 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R511# CARBON RES. 1/4W J 150k Ω RCX4JATZ0154
R512# CARBON RES. 1/4W J 150k Ω RCX4JATZ0154
R513# CARBON RES. 1/4W J 150k Ω RCX4JATZ0154
R514 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R516 CHIP RES.(1608) 1/10W J 15 Ω RRXAJB5Z0150
R517 A,B CARBON RES. 1/4W J 680 Ω or RCX4JATZ0681
A,B CARBON RES. 1/6W J 680 Ω RCX6JATZ0681
R517 C CARBON RES. 1/4W J 560 Ω or RCX4JATZ0561
C CARBON RES. 1/6W J 560 Ω RCX6JATZ0561
R518 CHIP RES.(1608) 1/10W J 15 Ω RRXAJB5Z0150
R519 A,B CARBON RES. 1/4W J 680 Ω or RCX4JATZ0681
A,B CARBON RES. 1/6W J 680 Ω RCX6JATZ0681
R519 C CARBON RES. 1/4W J 560 Ω or RCX4JATZ0561
C CARBON RES. 1/6W J 560 Ω RCX6JATZ0561
R520 CHIP RES.(1608) 1/10W J 15 Ω RRXAJB5Z0150
R521 A,B CARBON RES. 1/4W J 680 Ω or RCX4JATZ0681
A,B CARBON RES. 1/6W J 680 Ω RCX6JATZ0681
R521 C CARBON RES. 1/4W J 560 Ω or RCX4JATZ0561
C CARBON RES. 1/6W J 560 Ω RCX6JATZ0561
MISCELLANEOUS
CL501A A,B LEAD WIRE 3P/270 WX1T5300-101
CL501A C LEAD WIRE 3P/350 WX1T7300-101
CL504A A,B LEAD WIRE 4P/250 WX1T5300-102
CL504A C LEAD WIRE 4P 340MM WX1T7200-101
Ref. No. Mark Description Part No.
JK501# CRT SOCKET ISMS02S JSCC220PK003
Ref. No. Mark Description Part No.
SENSOR CBA
Consists of the followings
0ESA04524
Q201 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12
PHOTO TRANSISTOR MID-32A22 NPWZM1D32A22
Q202 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12
PHOTO TRANSISTOR MID-32A22 NPWZM1D32A22
Ref. No. Mark Description Part No.
