Sylvania SRC2213 - Mechanical Parts List

20020206 3-2-1 T5307CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
#
have special characteristics important to safety. Before
replacing any of these components, read carefully the
product safety notice in this service manual. Don't
degrade the safety of the product through improper ser-
vicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Comparison Chart of Models and Marks
[ SRC2213/SRC22134 ]
Model Mark
SRC2213 A
SRC22134 B
SRC22194 C
Ref. No. Mark Description Part No.
A1X A FRONT CABINET ASSEMBLY T5307UH 0EM101169
A1X B FRONT CABINET ASSEMBLY T5308UJ 0EM101170
A1-1 A FRONT CABINET T5300UA 0EM000619
A1-1 B FRONT CABINET T5308UJ 0EM101181
A1-2 A CONTROL PLATE T5307UH 0EM301605
A1-2 B CONTROL PLATE T5308UJ 0EM301606
A1-3 A BRAND PLATE T5307UH:SYLVANIA 0EM407053
A1-3 B BRAND PLATE T5308UJ:SYLVANIA 0EM407194
A1-4 A CASSETTE DOOR T5303UD 0EM406915
A1-4 B CASSETTE DOOR T5308UJ 0EM407195
A1-5 DOOR SPRING B5000UA or 0VM403773
DOOR SPRING(Z10) T5200UA 0EM406687
A2 A REAR CABINET T5303UD 0EM000604
A2 B REAR CABINET T5308UJ 0EM101182
A3# A RATING LABEL T5307UH ----------
A3# B RATING LABEL T5308UJ ----------
A4 A POP LABEL T5307UH 0EM407065
A4 B POP LABEL T5308UJ 0EM407096
1B1 A DECK ASSEMBLY CZD011/VM1426 N1426FT
1B1 B DECK ASSEMBLY CZD011/VM1446 N1446FT
B1 TENSION SPRING B0080B0:EM40808 26WH006
B2 M5 CRT SCREW(B) B4000UA 0VM403923
B3 SHIELD PLATE (Z11 13V) T5300UA 0EM406843
CL802 WIRE ASSEMBLY 2P/150 WX1B5900-001
CLN551 CRT GND WIRE CRT GND WX1L7720-001
DG601# DEGAUSSING COIL F-019 or LLBH00ZTM019
# DEGAUSSING COIL AVDG016 LLBH00ZWR016
L1 SCREW, P-TIGHT 4X18 BIND HEAD + GBMP4180
L4 SCREW, P-TIGHT 3X10 BIND HEAD GBUP3100
SP801 SPEAKER S08F02B or DSD0808XQ010
SPEAKER J-F097-C5 DSD0808DCP01
TB1 TRAY CHASSIS T5300UA 0EM000588
TB2 TOP SHIELD T5300UA 0EM301573
TB8 SPEAKER HOLDER T5100UA 0EM201157B
TB10 RCA HOLDER T5300UA 0EM406869
TB11 CLOTH(10X30XT0.5) B5900UA 0EM404486
TB23 TRAY COVER TD250UA 0EM406459
TL1 SCREW, P-TIGHT 3X12 WASHER HEAD+ GCMP3120
TL3 SCREW, S-TIGHT 3X4 BIND HEAD+ GBMS3040
TL13 SCREW, B-TIGHT M3X8 BIND HEAD+ GBMB3080
TL14 SCREW, B-TIGHT M3X8 BIND HEAD+ GBMB3080
TL15 SCREW TAPPING M4X14 DBU14140
TL16 SCREW, P-TIGHT 3X10 BIND HEAD+ GBMP3100
TL17 SCREW, P-TIGHT M3X10 WASHER
HEAD+
GCMP3100
PACKING
S1 A CARTON T5307UH 0EM407066
S1 B CARTON T5308UJ 0EM407050
S2 STYROFOAM TOP ASSEMBLY T5300UA 0EM406844
S3 STYROFOAM BOTTOM ASSEMBLY
T5300UA
0EM406845
S4 A SERIAL NO. LABEL T5307UH 0EM407068
S4 B SERIAL NO. LABEL T5308UJ 0EM407098
S6 SET SHEET B5506UG:800X1500 0EM402369
ACCESSORIES
X1 POLYETHYLENE BAG B5310UL Z223380
X2# A OWNER'S MANUAL T5307UH 0EMN01904
X2# B OWNER'S MANUAL T5308UJ 0EMN01907
X3 A REMOCON UNIT 512/ERC001/N0154UD
or
N0154UD
A REMOCON UNIT 512/ERC001/N0123UD N0123UD
X3 B REMOCON UNIT 512/ERC001/NE109UD NE109UD
X4 DRY BATTERY R6P UM3 or XB0M451GH001
DRY BATTERY R6P(AR)2PX or XB0M451HU002
DRY BATTERY R6P(AR)2P X ICI or XB0M451HU003
DRY BATTERY(SUNRISE) R6SSE/2S or XB0M451MS002
DRY BATTERY R6P/2S XB0M451T0001
X5 ROD ANTENNA T5200UA or 0EMN01755
ROD ANTENNA L7720UA:NTSC W/COO
or
0EMN00673
ROD ANTENNA T5000UA 0EMN01599
Note:
A number of different CRTs (V501) may be used in these models. Each CRT is used in
combination with a specific deflection yoke (L551). Refer to Table 1 and the following
parts list for details.
CRT TYPE A
L551# DEFLECTION YOKE LLBY00ZSY005 LLBY00ZSY005
V501# CRT A34AGT13X TCRT190CP036
V501-1 C.P.MAGNET JH225-FN-00 XM04000BV003
V501-2 WEDGE FT-00110W or XV10000T4001
WEDGE DB25SR XV10000D9001
V501-3 RUBBER MAGNET 20X10X1.2 XM05000BV001
CRT TYPE B
L551# DEFLECTION YOKE KDY3GDA82X LLBY00ZMS011
V501# CRT A34AGT13X TCRT190CP036
V501-1 C.P.MAGNET JH225-FN-00 XM04000BV003
V501-2 WEDGE FT-00110W or XV10000T4001
WEDGE DB25SR XV10000D9001
V501-3 RUBBER MAGNET 20X10X1.2 XM05000BV001
CRT TYPE C
L551# DEFLECTION YOKE LLBY00ZSY002 LLBY00ZSY002
V501# CRT A34KQW42X TCRT190SM013
V501-1 C.P.MAGNET JH225-FN-00 XM04000BV003
V501-2 WEDGE FT-00110W or XV10000T4001
WEDGE DB25SR XV10000D9001
V501-3 RUBBER MAGNET 20X10X1.2 XM05000BV001
Ref. No. Mark Description Part No.
