Sylvania SRC2213 - Precautions; Electrical Safety and Fire Prevention

1-1-1 T5307SP
SPECIFICATIONS
*ˆMode---------SP mode unless otherwise specified
*Test input terminal
<Except Tuner>-------------Video input (1Vp-p)
Audio input (-10dB)
<Tuner>-----------------------Ant. input (80dBµV) Video: 87.5%
Audio: 25kHz dev (1kHz Sin)
<DEFLECTION>
[ SRC2213/ SRC22134 ]
[ SRC22194 ]
<VIDEO & CHROMA>
[ SRC2213/ SRC22134 ]
Description Condition Unit Nominal Limit
1. Over Scan — % 90 —
2. Linearity Horizontal % — 15
Vertical % — 10
3. High Voltage — kV 22 —
Description Condition Unit Nominal Limit
1. Over Scan — % 90 —
2. Linearity Horizontal % — 15
Vertical % — 10
3. High Voltage — kV 25 —
Description Condition Unit Nominal Limit
1. Misconvergence Center m/m — 0.3
Corner m/m — 1.5
Side m/m — 1.2
2. Tint Control Range — deg ±30 —
3. Contrast Control Range — dB 6 4
4. Brightness APL 100% ft-L 55 40
5. Color Temperature — K 9200 —
