1-1-2 T5307SP
[ SRC22194 ]
<VCR>
<TUNER>
<AUDIO>
All items are measured across 8Ω resistor at speaker output terminal.
Note: Nominal specifications represent the design specifications. All units should be able to approximate these.
Some will exceed and some may drop slightly below these specifications. Limit specifications represent the abso-
lute worst condition that still might be considered acceptable. In no case should a unit fail to meet limit specifica-
tions.
Description Condition Unit Nominal Limit
1. Misconvergence Center m/m — 0.3
Corner m/m — 1.5
Side m/m — 1.2
2. Tint Control Range — deg ±30 —
3. Contrast Control Range — dB 6 4
4. Brightness APL 100% ft-L 35 40
5. Color Temperature — K 9200 —
Description Condition Unit Nominal Limit
1. Horizontal Resolution (R/P) Line 230 200
2. Jitter (Low) (R/P) µS 0.05 0.2
3. S/N Chroma AM(SP) (R/P) dB 38 33
PM(SP) (R/P) dB 36 33
4. Wow & Flutter (RMS) (R/P) % 0.25 0.5
Description Condition Unit Nominal Limit
1. Video S/N — dB 45 40
2. Audio S/N (W/LPF) — dB 43 40
Description Condition Unit Nominal Limit
1. Audio Output Power (Max.) (R/P) W 1.0 0.8
2. Audio S/N (W/LPF) (R/P) dB 40 36
3. Audio Distortion (W/LPF) (R/P) % 3.0 5.0
4. Audio Freq. Response
(-10dB Ref. 1KHz)
200Hz (R/P)
8kHz (R/P)
dB
dB
-2.0
0
-2.0±5.0
0±6.0
To Next Page
