24
17. SPECIFICATION
Model
AW12W-6/AW12W-F
Item Specification
Length 1870mm
Width 698mm
Height 1325mm
Wheel base 1325mm
Net Weight 109kg(Front:41kg Rear:68kg)
Model Single cylinder,4- stroke, forced air cooled engine
Fuel Unleaded gasoline
Displacement 124.6 c.c.
Compression ratio 9.6 :1
Maximum net power output 5.88kw/7500rpm
Net Maximum torque 8.33 N.m/6500 rpm
Idling speed 1650±100 rpm
Valve clearance: IN/EX 0.12±0.02/0.12±0.02 mm
Starting methods Kick & electrical starter
Front shock absorber Telescopic fork
Rear shock absorber Unit swing
Clutch Auto centrifugal type
Transmission C.V.T.
Front tire 110/70-12 47J
Rear tire 120/70-12 51J
Rim type Aluminum
Tire pressure
Front: STD 2.00 kg/cm
2
,
Rear: STD 2.00kg/cm
2
for 1 person, 2.25kg/cm
2
for 2 persons
Front brake Disk type (Ø 190 mm)
Rear brake Drum type (Ø 130 mm)
Head lamp(high, low) 12V 35/35W
Front position lamp 12V 5W
Front/ Rear direction
indicator
12V 10W
Rear position lamp/Stop
lamp
12V 5W/12V 21W
Rear registration plate lamp 12V 5W
Engine oil capacity 0.85 L (0.80 L for change)
Transmission oil capacity 105±5c.c (90c.c for change)
Fuel tank capacity 5.0L
Fuse 7A
Spark plug CR6HSA
Battery capacity 12V 7Ah(closed type, maintenance-free battery)
Air cleaner Paper type
