1. GENERAL INFORMATION/TROUBLE DIAGNOSIS SYM
1-10
TORQUE VALUES (ENGINE)
ITEM Q'TY
THREAD DIA
(mm)
TORQUE
VALUE(Kg-m)
REMARKS
A.C. generator fixing bolts 2 6 0.8~1.2
Pulse generator hex bolts 2 5 0.35~0.5
Gear oil filling bolt 1 8 1.0~1.4
Oil pump flat bolts 2 6 0.8~1.2
Crankcase flange bolts 2 6 0.8~1.2
Oil pump drive sprocket nut 1 6 0.8~1.2
Cylinder/cylinder head two-ends
bolts
4 8 0.7~1.1 Tighten to crankcase
Oil pump drive separator bolts 2 6 0.8~1.2
Cam holder nuts 4 8 1.8~2.2
Start clutch lock nut 1 22 9.0~10.0
Camshaft chain adjuster bolts 2 6 0.8~1.2
Cylinder head bolts 3 6 0.8~1.2
Cylinder head cover bolts 4 6 0.8~1.2
Right crankcase cover bolts 10 6 0.8~1.2
Flywheel nut 1 12 5.0~6.0
Shroud A/B tapping screws 3 5 0.8~1.2
Cooling fan bolts 4 6 0.8~1.2
Cooling fan cover 2 6 0.8~1.2
Transmission(Gear box) bolts 7 8 1.8~2.2
RR. brake arm bolt 1 6 0.8~1.2
Crankcase draining plug bolt 1 12 3.5~4.5
Drive pulley nut 1 12 5.0~6.0
Drive face nut 1 12 5.0~6.0
Start motor bolts 2 6 0.8~1.2
Left crankcase cover bolts 10 6 0.8~1.2
Carburetor nuts 2 6 0.8~1.2
A.I. fixing hex cap nuts 2 6 0.8~1.2
Valve adjustment fixing nuts 2 5 1.0~1.5 Apply oil to thread
Gear oil draining plug bolt 1 12 3.5~4.5
Camshaft chain tensioner pivot 1 6 0.8~1.2 Hex socket bolt
Spark plug 1 10 1.0~1.4
Engine oil strainer cap 1 30 1.0~2.0
Kick starter arm bolt 1 6 0.8~1.2
Exhaust pipe bolts 2 8 3.0~3.6
Exhaust pipe connecting nuts 2 6 1.0~1.4
