SYM 1. GENERAL INFORMATION/TROUBLE DIAGNOSIS
1-9
SPECIFICATIONS
MAKER SANYANG MODEL ALA125CC (AW12W-6)
Overall Length 1870mm Front TELESCOPIC FORK
Overall Width 698 mm
Suspen
sion
System
Rear UNIT SWING
Overall Height 1325 mm Front 110/70-12 47J
DIMENSION
Wheel Base 1325mm
Tire
Specifi
cations
Rear 120/70-12 51J
Front 41kg
Rear 68kg
Front DISK (ø 190 mm)
Curb Weight
Total 109kg
Brake
System
Rear DRUM (ø 130 mm)
Passengers/
Weight
Two men/110 kg Max. Speed ＞92km/h
Front 85kg
Performa
nce
Climb Ability ＞28°
Rear 134kg Primary Reduction BELT
WEIGHT
Total Weight
Total 219kg
Secondary
Reduction
GEAR
Type
4-STROKE ENGINE
(OHC)
Clutch Auto centrifugal clutch
Installation and
arrangement
Vertical, below center,
incline 80°
Deceleration
equipment
Transmission C.V.T.
Fuel Required Unleaded gasoline Speedometer 0 ~ 140 km/h
Cycle/Cooling
4-stroke/forced air
cooled
Horn 93~112dB
Bore 52.4 mm Muffler Expansion & Pulse Type
Stroke 57.8 mm
Exhaust Pipe Position
and Direction
Right side, and
Backward
Cylinder
Number/Arran
gement
Single Cylinder
Lubrication System
Forced-circulation&
splashing
Displacement 124.6 cc
CO <2.0 g/km
Compression
Ratio
9.6 : 1 HC
<0.8 g/km
Max. HP 6.25KW/8000 rpm
Exhaust
Emission
NOx <0.15 g/km
EURO3
Max. Torque 8.33N.m /6500 rpm
Air Filtration Paper filter
Ignition C.D.I.
Noise Emission < 77dB
ENGINE
Starting System Kick & electrical starter
Engine Weight(dry
weight)
30kg
