12. BODY COVER SYM
12-2
MAINTENANCE INFORMATION
Body covers disassemble sequence:
 Be careful not to damage various covers in disassembly or re-assembly operation.
 Never injure hooks molded on the body covers in disassembly or re-assembly operation.
 Align the buckles on the guards with slot on the covers.
 Make sure that each hook is properly installed during the assembly.
 Never compact forcefully or hammer the guard and the covers during assembly.
Battery cover
Luggage box & Seat
Front center cover
Front handle cover
Floor panel
Rear carrier
Rear fender
Rear handle cover
Front fender
Front cover
Inner box
Left/right body cover
Rear inner fender
Front cushion
Front spoiler
Left/right side cover
Under cover
