SYM 12. BODY COVER
12-1
MAINTENANCE INFORMATION........12-2
HANDLE COVER ...............................12-3
FRONT COVER..................................12-4
UNDER COVER .................................12-5
FRONT INNER BOX...........................12-6
BODY COVER/REAR FENDER.........12-7
FRONT CENTER COVER..................12-9
LUGGAGE BOX.................................12-9
FLOOR PANEL ..................................12-9
Front center
cover
Frame number
cover
Left body cover
Inner box
Double Seat
Rear carrier
Luggage box
Floor panel
Front cove
r
Under cover
Rear fender
Rear handle
cove
r
Front fende
r
Right body cover
Battery cover
RR. mudguard
Rear inner
fender
Fuel tank
Front handle
cove
r
Front spoiler
Left side cover
Right side cover
