SYM 12. BODY COVER
12-5
Remove the front turn left/right signal light
wire connectors.
Remove the front cover.
Installation:
Install according to the reverse procedure of
removal.
UNDER COVER
Removal
Remove the 1×2 mounting screws between
the left/right side cover and the floor panel.
Remove the 1×2 mounting screws between
the left/right side cover and the frame.
Remove the 2×2 mounting bolts between
the under cover and the frame.
Remove the under cover.
Installation:
Install according to the reverse procedure of
removal.
wire connecto
r
s
1×2 screws
1×2 screws
2×2 bolts
