Sym Fiddle II 50 SYM Series User Manual

SYM 13. BRAKE
13-1
MECHANISM DIAGRAM................................13-1
MAINTENANCE INFORMATION.......13-3
TROUBLE DIAGNOSIS .....................13-4
HYDRAULIC BRAKE SYSTEM
INSPECTION .....................................13-5
BRAKE FLUID REPLACEMENT/
AIR-BLEED........................................13-6
BRAKE CALIPER.............................. 13-7
BRAKE DISK ..................................... 13-8
BRAKE MASTER CYLINDER ........... 13-8
DRUM BRAKE-DRUM....................... 13-11
BRAKE LING..................................... 13-11
BRAKE PANEL.................................. 13-12
MECHANISM DIAGRAM
Front Disk Brake System
11.0~13.0 kgf-m
4.0~4.5 kgf-m
0.8~1.0 kgf-m
3.3~3.7 kgf-m
2.8~3.2 kgf-m
