10
○,c Trip Meter
This trip meter shows the distance in kilometers since it was last reset to zero.
In trip meter mode, quickly push S button twice to reset trip meter.
Display range: 0~999.9 km.
○,d Odometer
This odometer shows the total distance in kilometers the scooter has been ridden.
It cannot be reset.
○,e Coolant temperature gauge
This gauge displays the temperature of engine coolant.
Normally the first
○,a to third ○,b sector comes on indicates the engine
is working at its operating temperature. The coolant temperature
varies with changes in the weather and engine load. If the sixth sector
○,c comes on, when the scooter is in operation, stop the engine and
move the scooter to a safe place, and check the coolant level in the
reserve tank and the radiator fan (page 24).
NOTE :
• This trip meter only shows in kilometers.
NOTE :
• The data is maintained in the combination instrument even when the battery is disconnected.
• When the figures come to 99999, they will return to 0 and start working again.
• This odometer only shows in kilometers.
NOTE :
• This scooter is not equipped with a high coolant temperature indicator light.
• The coolant temperature gauge will not blink when the coolant temperature is too high.
•
Please take notice of the coolant temperature gauge when the engine is running.
○,a
○,b
○,c
