9
Battery Voltage Gauge
The battery voltage display shows current battery voltage. It is forced display about 10 seconds when the
ignition switch is turned on.
Display range: 8.0V~18.0V.
Ambient Temperature Gauge
This gauge shows current air temperature. To check out ambient temperature, push S button in battery
voltage mode. This gauge has 2 display modes as below:
Celsius mode: Display in thermometric scale of Celsius. Push S button to go to Fahrenheit mode.
Fahrenheit mode: Display in thermometric scale of Fahrenheit.
Display range: -20~50℃, -4~122℉.
○,b Oil Distance Meter
This meter records how long the engine oil is used. The oil check indicator light (page 6) goes on at every
1,000km riding distance according to this oil distance meter. When the oil check indicator light goes on,
please check the oil level in the oil level inspection window (page 22).
In oil distance mode, quickly push S button twice to reset oil distance meter.
Display range: 0~9999.9 km.
CAUTION:
• If the battery voltage is below 10.0V or above 16.0V when the ignition switch is turned on, and
the engine is hard to start or cannot be started, have your scooter checked by an authorized SYM
dealer.
• If the battery voltage is below 10.0V or above 16.0V when the engine is running, have your scooter
checked by an authorized SYM dealer.
NOTE :
• If the oil distance meter is not reset, the oil check indicator light will go on permanently until it is reset.
• If the oil distance meter is not reset, when the oil distance exceed the maximum limit 9999.9 km, the
meter will return to 0 km and continue adding up values. In this condition, the oil indicator light will not
go off until it is reset.
• This oil distance meter only shows in kilometers.
