7
○,D EFi Warning Indicator Light
When turn the main switch to “ON”, the EFi warning indicator remains on initially. It should be go off
immediately after the engine is running. It displays the condition of the EFi system is working correctly. If
there is any problem on the EFi system, the warning indicator remains on all the time or does not come
on. Please contact your SYM authorized dealer if this light goes on. This indicator light goes off when the
side stand is down (page 17).
○,E High Beam Indicator
This indicator turns on with high beam headlight is turned on.
○,F Tachometer
This tachometer shows the engine speed in revolutions per minute (rpm).
Do not operate the engine in the red zone
○,a.
○,G Fuel Gauge
This fuel gauge shows the fuel level. There are 10 sectors in the fuel gauge.
If the fuel tank is full, the needle will be in the “F” mark.
When the needle is in the red zone
○,a, go refuel the fuel tank immediately.
○,H Speedometer
The speedometer shows the current vehicle speed.
The outer hemisphere
○,a represents km/h.
The inner hemisphere
○,b represents mph.
○,I M Button
Press this button to switch meter mode of the multifunction meter.
○,J S Button
Press this button to switch between ambient temperatures, battery
voltage and clock in the multifunction meter.
This button is also designed to reset the trip meter, oil mileage meter
in the multifunction meter.
○,a
○,a
○,a
○,b
