30
13. PERIODICAL MAINTENANCE SCHEDULE
Maintenance
kilometer
300KM
Every
1000KM
Every
3000KM
Every
6000KM
Every
12000KM
Item
Check
Items
Maintenance
Interval
NEW 1 Month 3 Months 6 Months 1 Year
Remarks
1 Air cleaner element(Remark) I CCR
2 Fuel filter IIR
3 Tire, pressure II
4 Battery II
5
Brake and brake clearance
checking
IIIII
6 Spark plug II R
7 Carburetor(idle speed) II
8 Ignition timing IIIII
9 Steering bearing and handles II
10 Check Transmission for leakage II
11 Check crankcase for leakage II
12 Transmission Oil R Replacement for every 5000KM(5 Months)
13 Drive Belt/roller IR
14 Light / electrical / meters IIIII
15 Fuel tank switch and lines II
16
Throttle valve operation and
cable
II
17 Engine bolts and nuts II
18
Cylinder head, cylinder, and
piston
I
19 Exhaust system/cleaning carbon I
20 Greasing on chassis LL
21 Front/rear suspension II
22 Main/side stands I I/L
23 Clutch disk I
24 Operation of oil pump rod II
25
Brake mechanism/brake lining
(pad)
II
26 Bolts/nuts for each components II
The above maintenance schedule is established by taking the monthly 1000 kilometers as a
reference which ever comes first.
Have your scooter checked and adjusted periodically by your SYM Authorized Dealer or Franchised
Dealer to maintain the scooter at the optimum condition.
Code:I ~ Inspection, cleaning, and adjustment R ~ Replacement C ~ Cleaning (replaced if
necessary) L ~ Lubrication
Remark: 1. Clean or replace the air cleaner element more often when the scooter is operated on dusty
roads or in the Heavily- polluted environment.
2. Maintenance should be performed more often if the scooter is frequently operated in high
speed and after the scooter has accumulated a higher mileage
