8
Push the M button for more than 2 seconds, the hour display starts blinking.
Push the S button to adjust the hours.
Push the M button. The hour display stops blinking and the minute display starts blinking.
Push the S button to adjust the tens place in the minute display.
Push the M button. The tens place stops blinking and the unit display starts blinking.
Push the S button to adjust the units place in the minute display.
Push M button to finish clock setting.
Battery Voltage Gauge
The battery voltage display shows current battery voltage. It is forced display about 10 seconds when the
ignition switch is turned on.
Display range: 8.0V~18.0V.
○d Fuel Gauge
This digital fuel gauge shows the fuel level. There are 7 sectors in the fuel gauge.
If the fuel tank is full, all the 7 sectors come on ○a .
The low fuel level indicator light comes on when there’s only the
first sector ○b remains, go refuel the fuel tank immediately..
NOTE :
When the battery is disconnected, the clock is reset to 12:00 and starts working again when the battery
is reconnected.
If the clock is idled about 30 seconds while setting, it will exit setting mode automatically and starts
working again.
If the ignition switch is turned off while setting the clock, the clock will exit setting mode when the
ignition switch is turned on again.
The clock works normally by the backup power even the ignition switch is turned off.
CAUTION:
If the battery voltage is below 10.0V or above 16.0V when the ignition switch is turned on, and
the engine is hard to start or cannot be started, have your scooter checked by an authorized SYM
dealer.
If the battery voltage is below 10.0V or above 16.0V when the engine is running, have your scooter
checked by an authorized SYM dealer.
