7
○J Tachometer
This tachometer shows the engine speed in revolutions per minute (rpm).
Do not operate the engine in the red zone ○a .
○K Multifunction Meter
○a Side stand down indicator
○b Luggage box light indicator
○c Multifunction display
- Clock
- Battery voltage gauge
○d Fuel gauge
○e Coolant temperature gauge
○f Odometer
○g Trip meter
○h Oil distance meter
○a Side Stand Down Indicator
This indicator comes on when the side stand is kicked down. The engine cannot be started when the
side stand is down. The engine will be stopped if the side stand is kicked down while the engine is
running. This indicator goes off when the side stand is up.
○b Luggage Box Light Indicator
This indicator comes on when the luggage box light is lit up. This indicator goes off when the luggage
box light is off.
○c Multifunction Display
When the ignition switch is turned on, battery voltage will display for approximately 10 seconds.
Then the below display mode can be shifted circularly by pushing the M button.
Clock → Battery voltage → Clock…
Push S button to switch the below display mode:
Odometer → Trip meter → Oil meter → Odometer…
○L TCS Indicator (LW30W2-EU only)
This indicator blinks when traction control is intervening. If the traction control system is turned off, this
indicator will go on. This indicator goes on whenever the ignition switch is turned off and turned to “On”
position; this indicator will not go off until the engine is started. If the light does not go on after turning
the ignition switch on, or if the indicator remains on when the engine is started, have the scooter
checked by an authorized SYM dealer.
Clock
This clock displays only 24-hour mode.
To set the clock, do the below steps:
Turn the ignition switch on and wait for approximately 10 seconds until the clock displays.
