• Turn Signal Switch
Turn signal lights are used when turning left/right or changing lane.
Turn ignition switch to “ON”, and slide the turn signal switch to left or right. Then, the turn signal lights
will flash.
To release, simply return the turn signal light button to the original position.
Right-side turn signal light flashing means you intend to make a right turn.
Left-side turn signal light flashing means you intend to make a left turn.
SAFETY HELMET HOOK
• Hook the safety helmet chin belt onto the hook.
CAUTION:
• Do not hang the safety helmet onto this hook when riding to avoid damaging scooter and loosing
safety helmet’s function.
SADDLE LOCK
• Unlock:
Insert the ignition switch key and turn to left to unlock.
• Unlock:
Press this button down when ignition switch is in the “ON” position, the seat can be unlock.
• Lock:
Press the saddle down and it will be locked automatically.
After the saddle has been locked, check to make sure it has been locked properly by lightly lifting
the saddle.
CAUTION:
• Do not put the key inside the storage box after unlocking to avoid the key being locked inside the
storage box when the saddle is pressed down automatically.
•
Be sure to remove the key after the saddle has been locked.
STORAGE BOX
• This box is located under the saddle.
• Maximum load capacity: 10kg.
• Do not store valuables in the box.
• Make sure that the saddle has been locked completely after it was pressed down.
• Take out valuables before washing to avoid wetting these objects.
•
Do not place thermal sensitive objects in the box because of engine’s heat and high temperature.
CAUTION:
Make sure to take the key a
way with you before you lock your seat.
ENGING CONTROL SWITCH
• This switch is located in the luggage box, under the seat.
• To set on the ENG. control switch, switch it to〝ON〞or〝
〞.
• Switch to〝OFF〞or〝
〞，before start the engine.
• Be sure the seat locked preperly after set on the switch.
7.Use of Each Component
10
