• Water temperature gauge
To indicate engine coolant temperature.
When the main switch turns to “ON”, the pointer indicator should be below the (H) position when the
scooter is operating.
If the pointer indicator stays above (H) position. Please check the coolant level of spare coolant tank and
heck cooling fan for proper operation. c
CAUTION:
The indicator will stay above (H) position when engine is run under high temperature for a long period
f time. In this case, the only way to cool the engine is to stop the engine. o
• Function setting
There are two buttons on the speedometer, explanation as below :
1. SET button :
a. Under normal mode, press SET button shortly to change between ODO & TRIP displays.
b. Under TRIP display mode, press SET for 2 seconds to reset the trip readings.
c. Under ODO mode and the vehicle is standing still, press SET for above 2 seconds to enter CLOCK
mode. Press SET button shortly to increase the hour readings, once per one time. Then press SET for
2 seconds to enter tenth minute setting. Increase the tenth minute readings by pressing SET button
once per one time. Again press SET for 2 seconds to enter unit minute setting. Increase the unit
minute readings by pressing SET button once per one time. Press SET button for above 2 seconds to
exit CLOCK mode.
2. OIL button :
a. The oil indicator will be on every 1,000 km, to warn the user to check (change) engine oil. Every 1,000
km when the oil indicator is on, press OIL button for above 2 seconds to put it out.
7
7.Use of Each Component
