8
1. Rear brake lever
2. Rear view mirrors
3. Left handlebar switches
4. Rear brake fluid reservoir
5. Combination instrument
6. Front brake fluid reservoir
7. Right handlebar switches
8. Front brake lever
9. Throttle grip
10. USB power outlet
11. Right compartment
12. Ignition switch
13. Left compartment
1
2
3
4
6
7
2
5
8
13
12
10
11
9
