Symetrix 528E - Page 37

528E
35
EQ
STAGE
OU T P UT
PRE-AMPDE -E S S
OU T P UT I NP U TINPUT
SIDECHAIN
TIP=RETURN
RING=SEND
OU T P UTINPUT
EXPANDER/COMPRESSOR
OU T P UT
UNBALANCED
OU T P UT
OU T P U T S T AGE
INPUT
E QUALIZE R
Ground
Send
Return
Return
Send
(fr om E Q output)
(to E Q input)
LIN
Figure 9-1. Input and output connector wiring. These diagrams represent the majority of connectors used in
modern audio equipment. Locate the source connector in the left column and match it up with the des ti na tion
connector in the right column. Wire your cable according to the diagrams.
FROM UNBALANCED OUT
FROM NON-TRANSFORMER (ELECTRONIC)
BALANC ED OUTPUT
(TYPIC A L OF SYMETRIX PRO DUC TS)
FRO M BA LA N C ED O UT
FROM UNBALANCED OUT
FRO M BA LA N C ED O UT
FROM BALANCED OUT
FEM A LE XLR
PIN 1 = G ROUND
PIN 2 = HIG H
PIN 3 = LOW
MALE XLR
PIN 1 = G ROUND
PIN 2 = HIG H
PIN 3 = LOW
MALE TS PLUG
TIP = H IG H
SLEEV E = G RO UN D
+
LO W
MALE TRS PLUG
TIP = H IG H
RING = LO W
SLEEV E = G RO UND
MALE TRS PLUG
TIP = H IG H
RING = LO W
SLEEV E = G RO UND
MALE TS PLUG
TIP = H IG H
SLEEV E = G RO UND +
LO W
MALE TS PLUG
TIP = H IG H
SLEEV E = G RO UN D +
LO W
TERMINA L STRIP
(+) = HIG H
(-) = LOW
= G RO UND
TERMINA L STRIP
(+) = HIG H
(-) = LOW
= G RO UND
TERMINA L STRIP
(+) = HIG H
(-) = NO T USED
= G RO UND
FEM A LE XLR
PIN 1 = G ROUND + LO W
PIN 2 = HIG H
PIN 3 = NO T USED
2
2
2
3
3
3
1
1
1
RING
RING
SLEEVE
SLEEVE
TO B A LA N C E D I N
TO B A LA N C E D I N
TO UN B A LA N C E D I N
TI P
TI P
TO UN B A LA N C E D I N FR O M
TRANSFORMER COUPLED OR
FLOATING BALANC ED OUTPUT
TO B A LA N C E D I N
REV-B
Figure 9-2. Sidechain insert jack connections
